Riccar 1700/1800

Model: 1700/1800

Save
 Part Not Listed?Part Not Listed?
product name

Riccar 1700/1800

...
...
xx
Post Filter Cover Copper 1800 TAC-3622401120
...
xx
Bag RHH-6
...
1
Body Assembly TAC-3620411600
...
2
Motor Assembly TAC-3620005330
...
3
Cord Reel Assembly TAC-D390-1500
...
4
Main Pcb Assembly TAC-D395-0600
...
5
Pc Board Fuse TAC-5FJGD1532R
...
6
Screw Tapping TAC-7121402011
...
7
Spring Button TAC-3625110000
...
8
Button Switch TAC-3626607000
...
9
Hepa Filter TAC-3621908500
...
10
Post Filter Cover Blue 1700 TAC-3622401111
...
12
Power Brush Assembly TAC-SPB-250
...
13
Floor/Rug Tool TAC-3629309400
...
14
Floor Brush Assembly TAC-12HFB-SB
...
15
Wire Integrated Wand TAC-D390-4600B
...
15a
Button Lock Kit TAC-3624411460A
...
16
Wand Adaptor C390-2300

Riccar 1700/1800

...
...
1
Dust Compartment TAC-3620411500
...
2
Caster Shaft TAC-3624902000
...
3
Screw TAC-7048402012
...
4
Caster Body TAC-3620602900
...
5
Caster Wheel TAC-3624706400
...
6
Caster Wheel Axle TAC-3624902100
...
7
Parking Bracket TAC-3623007000
...
8
Screw T2S Pan 4X14 TAC-7121401411
...
9
Wire Harness TAC-D395-1700
...
10
Furniture Guard TAC-3628302000
...
11a
Bag Holder TAC-3623007100
...
11b
Bag Holder Spring TAC-3625109700
...
12
Secondary Filter Holder TAC-3621106100
...
13
Activated Charcoal Filter Charcoal TAC-3621908300
...
14
Bottom Motor Mount Natural Rubber Foam TAC-3620112700
...
15
Front Motor Mount Natural Rubber Foam TAC-3624008400
...
16
Silicone Rubber Tube TAC-3625700200
...
17
Cord Reel Assembly(Drawing Reversed) TAC-D390-1500

Riccar 1700/1800

...
...
1
Upper Compartment Body Blue 1700 TAC-3621434240
...
1A
Upper Compartment Body Copper 1800 TAC-3621434230
...
2
Upper Motor Mount TAC-3620102800
...
3
Main On/Off Switch TAC-3629002900
...
4
Filter Reset Button TAC-3624314200
...
5
Screw T2S Pan 3X14 TAC-7121301411
...
6
Pc Board Connector Assembly TAC-3624313900
...
7
Pc Board Mount TAC-3624008600
...
8
Dust Cover Assembly Blue 1700 TAC-3621435330
...
8A
Dust Cover Assembly Copper 1800 TAC-3621435310
...
9
Rear Compartment Bracket TAC-3625300600
...
10
Screw Tapping T2S Pan 4X14 TAC-7121401411
...
11
Cord Reel Spring TAC-3625110000
...
12
On/Off Button TAC-3626607000
...
13
Cord Reel Button TAC-3626607100
...
14
S-Class Hepa Filter(Includes Seal) TAC-3621908500
...
15
Post Filter Cover Blue 1700 TAC-3622401111
...
15A
Post Filter Cover Copper 1800 TAC-3622401120

Riccar 1700/1800

...
...
xx
Dust Cover Assembly Copper 1800 TAC-3621435310
...
xx
Dust Cover Assembly Blue 1700 TAC-3621435311
...
1
Dust Compartment Lid Blue 1700 TAC-3621434311
...
1A
Dust Compartment Lid Copper 1800 TAC-3621434320
...
2
Dust Compartment Tool Plate TAC-3624502400
...
3
Frame Terminal Assembly TAC-D395-1000
...
4
Hose Cuff Socket TAC-3629801900
...
5
Dust Cover Latch TAC-3621202900
...
6
Dust Cover Latch Spring TAC-3625106400
...
7
Dust Cover Latch Assembly TAC-D395-0100
...
8
Tool Lid Latch TAC-3621203000
...
9
Tool Cover Button TAC-3626606900
...
10
Latch Spring TAC-3625107900
...
11
Tool Cover Lid Dampener TAC-3626900200
...
12
Screw T2S Pan 3X12 TAC-7121301211
...
13
Screw T2S Pan 4X14 TAC-7121401411
...
14
Tool Cover Lid Spring TAC-3625110100
...
15
Tool Lid Blue 1700 TAC-3621434440
...
15A
Tool Lid Copper 1800 TAC-3621434420
...
16
Tool Lid Hinge TAC-3622900100

Riccar 1700/1800

...
...
2
Pcb Y Terminal Assembly TAC-3624314100
...
3
Pcb Handle Assembly TAC-3624502550
...
4
Cover Handle Right TAC-3621435000
...
5
Cover Handle Left TAC-3621435100
...
6
Screw T2S Pan 3X12 TAC-7121301212
...
7
Pipe Handle Inner TAC-3624415000
...
8
Cap Cover Handle TAC-3620904500
...
9
Terminal Subassembly TAC-3624314000
...
10
Screw T2S Pan 3X12 TAC-7121301012
...
11
Hose Handle Decal TAC-3621600700
...
12
Wire Harness Assembly TAC-36227151T0

Riccar 1700/1800

...
...
xx
Power Nozzle Copper 1800 RPB-250
...
1
Floor Brush Assembly TAC-3629309400
...
2
Brush Cover TAC-3621434500
...
2
Motor Packing TAC-3624008500
...
3
Brush Neck TAC-3624414700
...
3
Front Motor Mount TAC-3621106200
...
4
Rubber Wheel TAC-3624706500
...
4
Motor Wiring Harness TAC-D395-1700
...
5
Wheel Axle TAC-3624902200
...
5
Internal Motor Mount TAC-3627901100
...
6
Brush Front Assembly TAC-3629309800
...
6
Rear Motor Mount TAC-3621106300
...
7
Brush Rear Assembly TAC-3629309900
...
7
Screw T2S Pan 4X14 TAC-7121401411
...
8
Dusting Brush TAC-3629307110
...
8
Thermostat TAC-3629002100
...
9
Upholstery Nozzle TAC-3628101600
...
9
Screw 7121301011
...
10
Crevice Nozzle TAC-3628101514
...
10
Thermal Protector Wiring Harness TAC-3622714730
...
11
Power Nozzle Blue 1700 TAC-RPB-224
...
1700-1800
Motor TAC-3962820750

Riccar 1700/1800

...
...
xx
Carbon Brush Assembly (for replacement)-For Tek motors only TAC-A113-2900
...
xx
Carbon Brush-For Ametek/Lamb/Kaihang motors only TAC-A72
...
xx
Carbon Brush-for Duratek motors only TAC-A113-2500
...
1
Motor TAC-3962820750
...
2
Motor Packing TAC-3624008500
...
3
Front Motor Mount TAC-3621106200
...
4
Motor Wiring Harness TAC-D395-1700
...
5
Internal Motor Mount TAC-3627901100
...
6
Rear Motor Mount TAC-3621106300
...
7
Screw T2S Pan 4X14 TAC-7121401411
...
8
Thermostat TAC-3629002100
...
9
Screw 7121301011
...
10
Thermal Protector Wiring Harness TAC-3622714730
...
...
...
...
...
