Karcher VSP14/VSP18

Model: VSP14/VSP18

Save
 Part Not Listed?Part Not Listed?
product name

Karcher VSP14/VSP18

...
...
1
Upholstery Nozzle, Black WIN-86319290
...
1
Paper Bags, Versa-Matic Micro Filter WIN-98406410
...
1
Filter Bag Pack WIN-86000500
...
1
Extension Hose WIN-86137690
...
2
Crevice Nozzle, Black WIN-86319300
...
2
Exhaust Filter 34/470 WIN-86141370
...
2
Extension Tube, Black WIN-86409690
...
3
Motor Filter WIN-86143430
...
3
Round Brush Vsm-Tk, Gray Black WIN-86409700
...
4
Hospital Grade Filter WIN-86142690

Karcher VSP14/VSP18

...
...
1
Handle Grip, Complete, Black WIN-86407670
...
2
Handle Cover, Black WIN-86407680
...
3
Scr, M4 X 10 WIN-86144830
...
4A
Cable Vs18 - 17/3 Awg, Yellow WIN-86407660
...
4B
Cable Vs14, Yellow WIN-86407650
...
5
Handle WIN-86142150
...
6
Dust Bag Housing, Basalt Gray WIN-86408190
...
7
Internal Cover 370/470, Basalt Gray WIN-86408200
...
8
Seal, Filter Tube WIN-86144930
...
9
Seal WIN-86144900
...
10
Retaining Ring, Karcher Gray WIN-86408080
...
11
Clip, Dust Bag House-Sr12 WIN-86319250
...
12
Grommet, Black WIN-86319140
...
13
Terminal Block WIN-86146170
...
14
Cable Clamp WIN-86139110
...
15
Cover, Vse Brush Strip, Basalt Gray WIN-86408220
...
16
Carrying Handle, Karcher Gray WIN-86408230
...
17
Stop Spring (Hook) WIN-86145350
...
18
Cable Hook, Karcher Gray WIN-86408240
...
19
Handle Catch, Karcher Gray WIN-86408250
...
20
Clip 4 Din 6799 WIN-86140040
...
21
Locking Catch, Karcher Gray WIN-86408260
...
22
Locking Rod WIN-86143100
...
23
Terminal Block WIN-86146200
...
24
Cover, Terminal Block WIN-86140420
...
25
Connector, Basalt Gray WIN-86408270
...
26
Female Contact Holder WIN-86141590
...
27
Sound Insulation WIN-86145170
...
28
Vac Motor Seal WIN-86146380
...
29
Vac Motor WIN-86146410
...
29a
Carbon Brush Set 100/120V WIN-86139400
...
30
Motor Cover WIN-86143410
...
31
Motor Support Vsp WIN-86352880
...
32
Leaf Spring WIN-86143010
...
33
Clamp WIN-86139970
...
34
Connecting Rod WIN-86140230
...
35
Motor Filter WIN-86143430
...
36
Pc Board Cover WIN-86143760
...
36a
Circuit Board 120V 3-P Ul WIN-86139950
...
37
Fitting WIN-86141680
...
38
Grounding Wire WIN-86141990
...
39
Vacuum Tube Cover, Basalt Gray WIN-86408280
...
40
Lens, Bag Light Indicator WIN-86143040
...
41
Switch Button, Zinc Yellow WIN-86408290
...
42
Spring WIN-86145220
...
43
Internal Cable WIN-86142830
...
44
Exhaust Filter 370/470 WIN-86141370
...
45
Exhaust Filter Cover, Basalt Gray WIN-86408300
...
46
Motor Cover 370/470 Dual Motor, Bg WIN-86408310
...
47
Dust Bag Housing Bumper, Basalt Gray WIN-86408320
...
48
Front Cover Complete, Basalt Gray WIN-86408330
...
48a
Front Cover Seal WIN-86141840
...
49
Cover Release, Zinc Yellow WIN-86408340
...
50
Seal, Release Cover WIN-86144970
...
51
Plastic Axle Cover WIN-86143940
...
52
Bag Holder, Cpl WIN-86138040
...
53
Safety Catch Spring WIN-86144760
...
54
Safety Catch WIN-86144750
...
55
Sensor Filter Bag Pack (10Pk) WIN-86000500
...
56
Extension Tube, Black WIN-86319200
...
57
Hose, Sensor Silver WIN-86142650
...
58
Upholstery Nozzle, Black WIN-86319290
...
59
Crevice Nozzle, Black WIN-86319300
...
60
Scr, M3,9 X 13 Mm Din 7981 WIN-86147030
...
61
Scr, M3,9 X 16 Mm Din 7981 WIN-86147040
...
62
Hospital Grade Filter WIN-86142690
...
63
Retaining Button, Karcher Gray WIN-86408350

Karcher VSP14/VSP18

...
...
100
Chassis 14" WIN-86407840
...
101
Front Bottom Plate WIN-86363140
...
102
Bumper WIN-86407850
...
103
Retaining Bracket WIN-86363160
...
104
Rear Bottom Plate, Gray Black WIN-86407860
...
105
Foot Pedal, Zinc Yellow WIN-86407870
...
105a
Axle, Foot Pedal WIN-86378430
...
106
Swivel Neck Bearing WIN-86363190
...
107
Wheel, Black WIN-86322280
...
108
Axle Clamp WIN-86363200
...
109
Pile Adjustment Axle WIN-86363210
...
110
Pile Adjustment Wheel, Black WIN-86407880
...
111
Thrust Member WIN-86146220
...
112
Adjustment Button, Zinc Yellow WIN-86407890
...
113
Spring WIN-86145270
...
114
Brush Motor 120V, 175W WIN-86143500
...
114a
Brush Set, Carbon Vac Mtr WIN-86138390
...
115
Brush Motor Pulley Fm WIN-86309030
...
116
Belt, 333 3M Htdii-6 WIN-86138220
...
117
Swivel Neck Assembly Ul-Version WIN-86363680
...
118
Wire, Swivel Neck 3-Wire WIN-86363700
...
119
Swivel Neck Cover WIN-86145840
...
120
Swivel Neck Support WIN-86363260
...
121
Swivel Neck Support L.H WIN-86363270
...
122
Switch Lever WIN-86363710
...
123
Leaf WIN-86363410
...
124
Clamp WIN-86139970
...
125
Brush Pulley WIN-86363280
...
126
Printed Circuit Board 120V 175W 14" WIN-86363720
...
127
Brush Assembly Cpl WIN-86363300
...
128
Brush Strip 14 WIN-86002440
...
129
Bearing Block L.H. WIN-86363310
...
130
Bearing Block R.H., Black WIN-86407900
...
131
Brush Roller Release, Karcher Gray WIN-86407910
...
131a
Spring WIN-86363340
...
132
Support Lever WIN-86145450
...
133
Return Spring WIN-86345580
...
134
Power Head Cover Vsp 14", Basalt Gray WIN-86407920
...
135
Side Plate, Black WIN-86407930
...
136
Scr, 4X20-T20 Sts WIN-86144790
...
137
Scr,M4X12 Mm W/Washer WIN-86144850
...
138
Screw M4 X 14 WIN-86363370
...
139
Screw M4 X 30 WIN-86147170
...
140
Scr, M3,9 X 13 Mm Din 7981 WIN-86147030
...
141
Access Door, Zinc Yellow WIN-86407940
...
142
Lever WIN-86363400

Karcher VSP14/VSP18

...
...
100
Chassis 18, Black WIN-86408130
...
101
Front Bottom Plate, Gray Black WIN-86408140
...
102
Bumper, Black WIN-86408150
...
103
Retaining Bracket WIN-86363160
...
104
Rear Bottom Plate, Gray Black WIN-86408160
...
105
Foot Pedal, Zinc Gelb WIN-86407870
...
105a
Axle, Foot Pedal WIN-86378430
...
106
Swivel Neck Bearing WIN-86363190
...
107
Wheel, Black WIN-86322280
...
108
Axle Clamp WIN-86363200
...
109
Pile Adjustment Axle WIN-86363210
...
110
Pile Adjustment Wheel, Gray Black WIN-86407880
...
111
Thrust Member WIN-86146220
...
112
Adjustment Button, Zinc Yellow WIN-86407890
...
113
Spring WIN-86145270
...
114
Brush Motor 120V WIN-86363500
...
114a
Brush Set, Carbon Vac Mtr WIN-86138390
...
115
Motor Pulley WIN-86309030
...
116
Belt, 333 3M Htdii-6 WIN-86138220
...
117
Swivel Neck Assembly Ul-Version WIN-86363680
...
118
Wire, Swivel Neck 3-Wire WIN-86363700
...
119
Swivel Neck Cover 370/470 WIN-86145840
...
120
Swivel Neck Support WIN-86363260
...
121
Swivel Neck Support L.H WIN-86363270
...
122
Switch Lever WIN-86363710
...
123
Leaf WIN-86363410
...
124
Clamp WIN-86139970
...
125
Brush Pulley WIN-86363280
...
126
Printed Circuit Board 120V 200W 18" WIN-86363740
...
127
Brush Assembly Cpl 18" WIN-86372960
...
128
Brush Strip, 18" Model U19840 WIN-86001640
...
129
Bearing Block L.H. WIN-86363310
...
130
Bearing Block R.H., Black WIN-86407900
...
131
Brush Roller Release, Karcher Gray WIN-86407910
...
131a
Spring WIN-86363340
...
132
Support Lever WIN-86145450
...
133
Spring Vse Return WIN-86345580
...
134
Power Head Cover Vs 18", Black WIN-86408180
...
135
Side Plate, Black WIN-86407930
...
136
Scr, 4X20-T20 Sts WIN-86144790
...
137
Scr,M4X12 Mm W/Washer WIN-86144850
...
138
Screw M4 X 14 WIN-86363370
...
139
Screw M4 X 30 WIN-86147170
...
140
Scr, M3,9 X 13 Mm Din 7981 WIN-86147030
...
141
Access Door, Zinc Yellow WIN-86407940
...
142
Lever WIN-86363400

Karcher VSP14/VSP18

...
...
xx
Sensor Filter Bag Pack (10Pk) WIN-86000500
...
xx
Exhaust Filter 370/470 WIN-86141370
...
xx
Motor Filter WIN-86143430
...
xx
Belt, 333 3M Htdii-6 WIN-86138220
...
xx
Cable Vs18 - 17/3 Awg, Yellow WIN-86407660
...
xx
Cable Vs14, Yellow WIN-86407650
...
xx
Brush Strip, 14" WIN-86002440
...
xx
Brush Strip, 18" Model U19840 WIN-86001640
...
...
...
...
...
