Karcher Sensor S 15

Model: Sensor S 15

Save
 Part Not Listed?Part Not Listed?
product name

Karcher Sensor S 15

...
...
XX
Upholstery Nozzle WIN-86146310
...
XX
Crevice Nozzle WIN-86140860
...
XX
Hose, Sensor Gry WIN-86142650
...
XX
Extension Tube Gry WIN-86141550

Karcher Sensor S 15

...
...
XX
<span class="fine-print">01. Handle Complete WIN-86142430
...
XX
</span> FNLA
...
02
Handle Grip, Sr Gry WIN-86142340
...
03
Grommet WIN-86141970
...
04
Cord Set, 18/3 Sjt Rib X 40 Blu WIN-86135510
...
05
Switch / Blue WIN-86319160
...
06
Switch Cap WIN-86145640
...
07
Switch Cap Holder Gry WIN-86145700
...
08
Cable Clamp WIN-86139280
...
09
Screw C 3,9x16 Din 7981 WIN-86147040
...
10
Antistatic-Wire WIN-86137780
...
11
Handle Cable 3wire W/Connector WIN-86142310
...
12
Screw, M4 X 12mm WIN-86147140
...
13
Handle Tube WIN-86142300
...
14
Scr M3, 9 X 13 Mm Din 7981 WIN-86147030
...
15
Sb Hose, Sensor Gry WIN-86142650
...
16
Hg Extension Tube, Gry WIN-86141550

Karcher Sensor S 15

...
...
17
Hg Cover WIN-86140830
...
18
Spring , Bag Holder WIN-86145340
...
19
Bl Cover Release, Blue WIN-86140810
...
20
Bag Holder WIN-86138050
...
21
Safety Catch, Bag Holder WIN-86144770
...
22
Safety Catch Spring WIN-86144760
...
23
Front Cover Cpl. WIN-86141860
...
24
Sensor Filter Bag Pack WIN-86000500
...
25
Er Micro Hygiene Filter WIN-86005220
...
26
Internal Cover WIN-86142910
...
27
Cable Clamp WIN-86139290
...
28
Filter Safety Catch WIN-86141620
...
29
Spring (Micro Filter Catch) WIN-86145320
...
30
Clamp WIN-86139970
...
31
Handle Lock Plate WIN-86142290
...
32
Hg Lock Catch WIN-86143140
...
33
Lock Pin WIN-86143060
...
34
Hg Carrying Handle Gry WIN-86139450
...
35
Stop Spring, (Hook) WIN-86145350
...
36
Hg Cable Hook Lt Gry WIN-86139260
...
37
Dg Retaining Ring, Dk Gry WIN-86144620
...
38
Dust Bag Housing, 3-Wire, Gry WIN-86141190
...
39
Clip, Dust Bag House Sr12 WIN-86140080
...
40
Spring, Locking Rod WIN-86145280
...
41
Internal Cable 3wire Loose Con WIN-86142880
...
42
Cable Clamp (Filter Bag Housing) WIN-86139320
...
43
Seal WIN-86144490
...
44
Seal, Filter Tube WIN-86144930
...
45
Seal, Filter Bag Housing Neck WIN-86144910
...
46
Dust Bag Housing Bumper Base WIN-86141120
...
47
Dust Bag Housing Locking Catch WIN-86141090
...
48
Locking Rod, Dust Bag Holder WIN-86143120
...
49
Dust Bag Housing, Srs, 3-Wire. WIN-86141190
...
50
Upholstery Nozzle WIN-86146310
...
51
Crevice Nozzle WIN-86140860

Karcher Sensor S 15

...
...
100
Power Head Cover Srs 15, Cpl. WIN-86144150
...
101
Exhaust Filter WIN-86141400
...
102
Exhaust Filter Cover WIN-86141380
...
103
Swivel Neck Assembly WIN-86145910
...
104
Male Contact Holder WIN-86143180
...
105
Cable Clamp WIN-86139230
...
106
Screw 3,9x13 Din 7981 WIN-86147030
...
107
Bypass Valve WIN-86139100
...
108
Internal Cable WIN-86142790
...
109
Swivel Neck Bearing R.H. WIN-86145900
...
110
Swivel Neck Support R.H. WIN-86145890
...
111
Swivel Neck Support L.H. WIN-86146110
...
112
Swivel Neck Bearing L.H. WIN-86146130
...
113
Pcb Power Supply WIN-86143800
...
114
Internal Cable, Ribbon WIN-86142780
...
115
Brush Roller Release, Srs15 WIN-86138500
...
116
Spring WIN-86145290
...
117
Axle Assembly Gry WIN-86137980
...
118
Axle WIN-86137990
...
119
Foot Pedal WIN-86293260
...
120
Wheel Return Spring WIN-86146570
...
121
Wheel, Cpl. WIN-86146670
...
122
Clamp Connecting Rod (Axle) WIN-86140000
...
123
Brush Roller 15' WIN-86138490
...
124
Bearing Blk, Rh Sr12 Blu/Gry WIN-86138170
...
125
Rubbing Plate WIN-86144700
...
126
Access Door SEB-2868OR
...
127
Axle , Access Door WIN-86138000
...
128
Spring , Access Door WIN-86145330
...
129
Pile Adjustment Axle WIN-86143850
...
130
Pile Adjustment Wheel Gry WIN-86143920
...
131
Axle Clamp WIN-86137920
...
132
Screw M 4 X 6,Din 7985 WIN-86144860
...
133
Cover WIN-86140620
...
134
Thrust Member WIN-86146220
...
135
Pile Adjustment Knob WIN-86143860
...
136
Thrust Member WIN-86146230
...
137
Clamp WIN-86140010
...
138
Spring WIN-86145250
...
139
Chassis Srs15, Cpl WIN-86139740
...
140
Front Bottom Plate Srs15 WIN-86141760
...
141
Rear Bottom Plate Srs15, Cpl WIN-86144530
...
142
Scr, M4x12 Mm W/Washer WIN-86144850
...
143
Wire Tie, Bottom Plate, Outer WIN-86146790
...
144
Wire Tie, Bottom Plate, Center WIN-86146800
...
145
Bumper, Set WIN-86138880
...
146
Carbon Brush Set 100/120v WIN-86139400
...
146
Thermo Switch Vac WIN-86146210
...
146
Motor 1000 W / 120 V WIN-86143630
...
147
Motor Pulley 2mr WIN-86143620
...
148
Rubber Mounting WIN-86144710
...
149
Motor Cover WIN-86143490
...
150
Cover For Air Channel WIN-86140610
...
151
Support Lever WIN-86145470
...
152
Support Spring WIN-86145460
...
153
Motor Pulley Cover WIN-86143570
...
154
Computer Controller WIN-86140150
...
155
Screw 2,9 X 13 WIN-86147160
...
156
Washer 3,2 WIN-86147190
...
157
Sensor (With Red Ring) WIN-86145060
...
158
Motor Pulley WIN-86143580
...
159
Scr, M3.9 X 25 Mm WIN-86147050
...
160
Belt 2mr-310-6 WIN-86138240
...
161
Belt Htd-Ii, 219 3m WIN-86005000
...
162
Bearing Block L.H. WIN-86138200
...
163
Screw C 3, 9x16 WIN-86016900
...
164
Washer WIN-86146540
...
165
Screw M4 X 30 WIN-86147170
...
...
...
...
...
