C5712- Eureka Commercial Vacuum

Model: C5712

Save
 Part Not Listed?Part Not Listed?
product name

Eureka C5712

...
...
1
Hose Assembly - Cartoned EES-61865-4
...
2
Adapter - Hose EES-71725-313N
...
3
Nesting Wand Assembly (C5712A-1) EES-77505-22
...
3
Nesting Wand Assembly EES-77505-29
...
4
Wand - Crevice EES-77506-355N
...
5
Wand - Outer EES-77507-119N
...
6
Coupling - Hose EES-70559A-119N
...
7
Combination Brush Brstld-C EES-60990-2
...
8
Package - Hardware EES-72322SV
...
9
Owner's Guide 76062

Eureka C5712

...
...
xx
Dampener - End Cap (Rh) (C5712A-1) EES-82559-316N
...
xx
Dampener - End Cap (Lh) (C5712A-1) EES-82558-316N
...
1
Base Hose Assembly EES-72001A
...
2
Base Hose Assembly EES-72001A
...
3
Felt - Base EES-73153
...
4
Knob - Height Adjustment EES-71448-355N
...
5
Base Assembly - Packaged EES-62411-1
...
6
Spring Package EES-54943
...
7
Carriage - Wheel EES-71446A-119N
...
8
Axle - Front EES-71478
...
9
Wheel - Front EES-39173A-119N
...
10
Belt Pkg Assembly - Style U Ext EES-61120A
...
12
Base Hose Assembly EES-72001A
...
13
Screw Package EES-53238-44
...
14
Hood Assembly - Packaged EES-62412-2
...
14
Hood Assembly - Packaged (C5712A-1) EES-62412-3
...
15
Spring - Handle Release EES-71574
...
16
Screw Package EES-53238-27
...
17
Clamp - Motor EES-71487
...
18
Release - Handle EES-71457-355N
...
19
Package - Retaining Ring EES-54432-2
...
20
Wheel/Bushing Package EES-61875-1
...
21
Bushing - Axle EES-73432
...
22
Axle - Rear EES-38590A
...
23
Belt Cap Assembly EES-71741A
...
24
Felt - Belt Cap EES-73152
...
25
12" Disturbulator Assembly EES-60844-10
...
26
Guard - Furniture EES-71456-355N
...
27
Guard - Belt EES-38063

Eureka C5712

...
...
1A
Grip - Left Handle EES-15596-355N
...
1B
Grip - Right Handle EES-15597-355N
...
2
Upper Handle Assembly EES-73175-1SV
...
3
Adapter - Clip EES-71746-119N
...
4
Bag Cover Latch EES-71830-308N
...
5
Spring EES-71852
...
6
Bag Cover Assembly - Packaged (C5712A-1) EES-61880-11
...
6
Bag Cover Assembly - Packaged EES-61880-10
...
7
Bag-In-Place Arm EES-71747-119N
...
8
Retainer - Cord EES-28316-355N
...
9
Screw Package EES-53238-44
...
10
Spring - Torsion EES-71748
...
11
Paper Bag Package - Style EES-61820B
...
12
Gasket - Adapter EES-71854
...
13
Gasket - Bag Cover EES-71512
...
14
Gasket - Lower Bag EES-71765A

Eureka C5712

...
...
xx
= Part is correct, but not shown on schematic. FNLA
...
1
Supply Cord & Terminal Assembly EES-38680-32
...
2
Switch - Rocker EES-28073A
...
3
Wire Splice 5 EES-60192-1
...
4
Rear Housing Assembly EES-71744-2
...
5
Gasket - Motor Can EES-75348
...
6
Motor Assembly 60261-10
...
6
Motor Assembly - Packaged (C5712A-1) 62394-1
...
7
Motor Screen EES-71851-119N
...
8
Filter - Pre-Motor EES-71480
...
9
Motor Cover Assy - Packaged EES-61879-6
...
9
Motor Cover Assy - Packaged (C5712A-1) EES-61879-8
...
11
Lens - Headlamp EES-71460-313N
...
12
Screw Package EES-53238-44
...
13
Socket Assembly EES-70513-4
...
14
Lamp - Headlight EES-57940-3
...
15
Thermostat & Terminal Assembly EES-39252-1
...
16
Switch Cover Assembly EES-72127-1
...
19
Tool Pack - Lower EES-71455-119N
...
20
Screw Package EES-53238-27
...
21
Hepa Filter Package - Style H EES-61830B
...
22
Filter Cover & Graphics EES-72006-12
...
23
Bushing - Motor Support EES-70084
...
24
Gasket - Motor Cover EES-71484
...
25
Gasket - Motor Hub EES-71969-1
...
26
Cord - Jumper EES-71465
...
26
Cord - Jumper (C5712A-1) EES-71465-3
...
27
Foam - Sound EES-72224-1
...
28
Tube - Flexible EES-70651-1
...
29
Plug EES-72167
...
...
...
...
...
