Hex Bolt 5/16-18 x .75" Lg. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0118
4
Lock Wash. 5/16" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0119
Lock Wash. 5/16" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-936-0119
Hex Bolt 3/8-24 x 1.25" Used with keyed engine crankshaft.; For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0191
xx
SCREW 3/8-24X2.25 GR8 Used with tapered engine crankshaft.
MTD-710-1254
HEX SCREW SEMS 5/16-18 x .62 For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part number and size as shown on parts list.
MTD-710-0259
Sq. Key 1/4" x 1/4" x 2.00" Used with keyed engine crankshaft; For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by parts number and size as shown on parts list.
MTD-914-0114
6
SCREW 5/16-18 x 1.5 LG For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by parts number and size as shown on parts list.
MTD-710-0805A
Lock Wash. 5/16" I.D. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by parts number and size as shown on parts list.
MTD-936-0119
9
HEX NUT 5/16-18 For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by parts number and size as shown on parts list.
MTD-712-3010
HEX NUT For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by parts number and size as shown on parts list.
MTD-712-0206
Hex Bolt 5/16-18 x .75" Lg. For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by parts number and size as shown on parts list.
MTD-710-0118
