product name

CleanMax ZM-600 Upright Vacuum

Model: ZM-600

Save
 Part Not Listed?Part Not Listed?
product name

CleanMax ZM-600

...
...
xx
Nylon Brush Strips (Long) TAC-B475-0400B
...
xx
Nylon Brush Strips (Short) TAC-B013-1000
...
1
Nozzle Housing Assembly TAC-D017-5014
...
2
Furniture Guard TAC-B029-0314
...
3
Screws TAC-A732-8314
...
4
Belt TAC-B014-1200
...
5
Hall Sensor Idler Assembly TAC-D375-1400
...
6
Rear Wheel Assembly W/Axle TAC-D350-6631
...
7
Base Tray Assembly TAC-D016-1114
...
8
Base Plate Wheel Assembly TAC-D010-2631
...
9
Metal Agitator Assembly TAC-D013-0500
...
10
Basetray Cover With Squeegee TAC-B015-3114
...
11
Bottom Plate Wheels TAC-B370-1843
...
12
Bottom Plate Axles TAC-B370-1700
...
13
Basetray Cover Squeege TAC-B015-3000B
...
14
Hex Nut TAC-A432-0805
...
15
Lower Handle Upper Fan Housing Assembly TAC-D431-3014
...
16
Fan Duct Cover With Seal Assembly TAC-D123-3814
...
17
Motor Seal Kit TAC-C121-0000
...
18
Lower Fan Housing TAC-B123-3614
...
19
Fan TAC-B123-3000
...
20
Fan Washer (For Replacement) TAC-A732-9305
...
22
Motor/Fan Assembly TAC-D113-1400
...
23
Combination Screw (M4 X 12) TAC-A732-2500
...
24
Upright Stop Plastic TAC-B016-1230
...
25
Strain Relief Washer TAC-B034-0100
...
26
Pc Board TAC-B317-1000BK
...
27
Plastic Dowel TAC-A018-1300
...
28
Basetray Cover Assembly TAC-D015-2914
...
29
Screws TAC-A732-9206

CleanMax ZM-600

...
...
xx
Papter Bag (6 Pack) TAC-CMZM-P6
...
1
Handle Assembly TAC-D431-3600
...
2
Handle Right/Left Assembly TAC-C431-3614
...
3
Screw, #8 X 5/8" TAC-A732-8314
...
4
Screw, #8 X 7/16" TAC-A732-8414
...
5
Main Switch Handle TAC-A428-2200
...
6
Wire Connectors Med. TAC-B123-0100
...
7
Handle Back TAC-B431-3314C
...
8
Upper Cord Hook TAC-B384-0900
...
9
Upper Cord Hook Washer TAC-A430-1100
...
10
Upper Cord Hook Screw TAC-A430-0205
...
11
Handle Cord Harness TAC-A434-3514
...
12
Handle Tube TAC-B431-3504E
...
13
Screw. #10- 32X1.625 TAC-A432-0705
...
14
Steel Cord Hook TAC-B430-1205
...
15
Handle Tube Bracket TAC-B431-2914E
...
16
Hex Nut TAC-A432-0805
...
17
Lower Handle Upper Fan Housing Assembly TAC-D431-3014
...
18
Fan Duct Cover With Seal Assembly TAC-D123-3814
...
19
Motor Seal Kit TAC-C121-0000
...
20
Lower Fan Housing TAC-B123-3614
...
21
Fan TAC-B123-3000
...
23
Motor/Fan Assembly TAC-D113-1400
...
24
Bag Collar Bag Holder Assembly TAC-D211-3614
...
25
Cloth Bag TAC-B211-6500D
...
26
Lower Bag Spring TAC-B211-1204
...
27
Lower Bag Clip TAC-B211-1914F
...
28
Hepa Bag (6 Pack) TAC-CMZM-H6
...
29
Power Cord Upgrade Kit TAC-D434-3714
...
30
Fan Washer (For Replacement) TAC-A732-9305
...
31
Screw TAC-A732-9206
...
32
Bag Collar Seal TAC-D211-5700
...
33
Power Cord TAC-A434-3341
...
34
Strain Relief TAC-A434-2714C
...
...
...
...
...
